Automatic End-Face Grinder

Function. Grinds flat, parallel end faces automatically with a variable-rate feed across the specimen.

Controlled. Variable feed rate; grind depth.

Measured. End-face flatness and parallelism.

Sample size, capacity, materials, tooling and instrumentation are configured per project. Guaranteed performance and included hardware are stated only in the project-specific technical proposal and approved datasheet.

Features

• Standard: ASTM D4543
• Core Diameter: 20 mm to 170 mm
• Core Length: up to 400 mm
• Grinding wheel precision: +/- 0.001 inch (2.5 / 100 mm)
• Grinding wheel diameter: 300 mm
• Grinding Wheel speed: 1,100 rpm
• Power supply: 220 VAC , 50/60 Hz
• Motor power: 2,200 watts
• Weight: 250kg
• Volume: 780x1600x1260 mm

Benefits

• Fully automated operation
• ASTM-compliant
• Heavy duty design
