Small Stirred Pressure Autoclave Reactors

  • LESSPARH autoclaves are small pressure vessels of 50 to 500 ml stirred from below by a magnetic stirrer, with no shaft passing through the head. They let the user measure pressure, temperature and stirring speed at the same time, add inert gas protection, release pressure, and take samples or feed reactants online. A glass window in the vessel lets the operator watch the contents. Volumes up to 2000 ml can be customized.

    Design

    Modular electric heating is listed at 600 W for the 50 and 100 ml vessels, 1.5 kW for the 250 ml vessel and 2.0 kW for the 500 ml vessel.

    Standard pressure is 100 bar, with designs up to 350 bar. Stirring is by bottom magnetic stirring at 0 to 1500 rpm. The stirring drive is 40 W on the 50, 100 and 250 ml vessels and 80 W on the 500 ml vessel.

    The standard material is SS304L. SS316L, TA2 titanium, C-276, nickel and zirconium are optional, as is a PTFE liner. The PTFE liner is limited to 180℃; above that temperature with corrosive media, choose a metal vessel. The operating temperature limit with magnetic stirring is provided on request for the selected vessel, magnet and liner configuration.

    Ports: inlet port and outlet port, pressure gauge, temperature measuring port and glass window. A feeding valve and a sampling valve are optional.

    Typical applications

    • Gas and liquid storage or charging under pressure
    • Acid digestion
    • Static, loop, electrochemical and corrosion studies
    • Supercritical fluid extraction
    • Hydrogen induced disbonding tests
    • Soaking of diamonds and precious stones
    • Hydrogenation, polymer polymerization, organic synthesis

    Specify for your project

    • Volume: 50, 100, 250 or 500 ml, or custom up to 2000 ml
    • Pressure: 100 bar standard or up to 350 bar
    • Material: SS304L, SS316L, TA2, C-276, nickel, zirconium, PTFE liner
    • Operating temperature and medium
    • Feeding valve and sampling valve

    Models: LESSPARH-50 (50 ml), LESSPARH-100 (100 ml), LESSPARH-250 (250 ml), LESSPARH-500 (500 ml).

    This description defines the product family. Guaranteed performance, included hardware, exclusions, interfaces and acceptance criteria are stated only in the project-specific technical proposal and approved datasheet.

    • Small Stirred Pressure Autoclave Reactors
  • Product features

    Small Stirred Pressure Autoclave Reactors
    Small Stirred Pressure Autoclave Reactors
    Small Stirred Pressure Autoclave Reactors
    Small Stirred Pressure Autoclave Reactors

    Product parameters

    Model LESSPARH-50 LESSPARH-100 LESSPARH-250 LESSPARH-500
    Material capacity 50ml 100ml 250ml 500ml
    Max temperature Operate pressure on request
    Standard 100bar; Max pressure up to 350bar
    Heating mode Module heating
    The heating power 600W 600W 1.5KW 2.0KW
    Stirring speed 0-1500rpm
    Stirring method Bottom magnetic stirring
    The stirring power 40 W 40 W 40W 80 W
    MOC SS304L standard: (SS316L, TA2, C-276. Nickel, Zirconium PTFE liner optional)
    Others Two ports(lnlet and outlet port); pressure gauge; temp. Measure port; Glass window; Feeding valve(optional); sampling valve(Optional)

    Remarks:

    1. Max volume 2000ml could be customized.
    2. The operating temperature limit is provided on request for the selected configuration. The optional PTFE liner has a maximum temperature of 180 °C; a compatible metal vessel is required for corrosive service above that limit.
    3. The reactor uses modular heating and internal magnetic stirring. Elevated temperature can reduce magnet strength. The allowable temperature with stirring is provided on request for the selected configuration.
