Solvent Recovery Still

Function. Separates crude oil from solvents used in extraction by fractional distillation for solvent reuse.

Controlled. Distillation temperature.

Measured. Recovered solvent and crude fractions.

Sample size, capacity, materials, tooling and instrumentation are configured per project. Guaranteed performance and included hardware are stated only in the project-specific technical proposal and approved datasheet.

Features

• Recovery: 95 %
• Recovery time: 3 to 5 hours for 20 litres
• Max temperature: 200°C
• Tank capacity: 20 litres, other upon request
• Protection: IP 66
• Material: stainless steel
• House water consumption: 50 litres per hour
• Power supply: 220 VAC 50 Hz , 2,500 W
• Dimensions: 850x1000x1000 mm
• Weight: 165 Kg
