Heavy-Oil Viscometer

Function. Determines the viscosity of heavy oil using a corrosion-resistant rod vibrated electromagnetically at constant power.

Controlled. Cell pressure and temperature.

Measured. Dynamic viscosity.

Volume, pressure and temperature ratings, wetted materials and instrumentation are configured per project. Guaranteed performance and included hardware are stated only in the project-specific technical proposal and approved datasheet.

Features

• Viscosity range: 10,000 cp to 1 million Cp (model A)
• Accuracy: 3% RM
• Repeatability: ±0.2%
• Volume of sample: 15cc
• Working temperature: up to 180 °C
• Working pressure: 10,000 psi (700 bar)
• Construction: Stainless Steel 316L, Hastelloy

Benefits

• Sensor without moving parts
• Very high viscosity range
• Robust and reliable
• Accurate
• Zero maintenance
