Electromagnetic Viscometer

Function. Determines viscosity using two coils that drive a piston back and forth in the fluid (electromagnetic method).

Controlled. Cell pressure and temperature.

Measured. Dynamic viscosity.

Volume, pressure and temperature ratings, wetted materials and instrumentation are configured per project. Guaranteed performance and included hardware are stated only in the project-specific technical proposal and approved datasheet.

Features

• Brand : Cambridge Electromagnetic Viscometer , SPSL 440 model
• Temperature range : up to 190°C
• Pressure range : up to 15,000 psi
• Viscosity range : 0.2 cP to 10,000 cP
• Accuracy : +/- 1% FS
• Reproducibility : +/- 0.8 % of reading
• Temperature sensor : Internal platinum RTD
• Wetted material : Inconel 718
• Temperature regulation : ± 0.5 oC
• Power supply : 220 VAC 50 Hz

Benefits

• Accurate measurement
• Calibration procedure provided
• Reservoir conditions
• Large viscosity range
