Capillary Viscometer

Function. Determines the viscosity of single-phase reservoir fluids at high pressure by the capillary method.

Controlled. Cell pressure and temperature; flow rate.

Measured. Dynamic viscosity.

Volume, pressure and temperature ratings, wetted materials and instrumentation are configured per project. Guaranteed performance and included hardware are stated only in the project-specific technical proposal and approved datasheet.

Features

• Viscosity range: 0,02 cp to 10,000 cp Sample volume: 10 ml
• Pressure: 15,000 psi
• Temperature: Ambient to 200 °C (400°F)
• Temperature regulation: ± 0.5 °C
• Pressure accuracy: 0.02% full scale
• Wetted parts: stainless steel
• Power supply: 220 VAC 50/60 Hz

Benefits

• Accurate viscosity measurement
• Provided with calibration procedure
• Broad viscosity range
