Double Ferrules Tube Union Elbows

Double Ferrule Tube Union Elbows turn a tubing run through a corner while keeping a leak-tight seal at both ends. The listed model SS-UE-FT8 is stainless steel SS316 for 1/2 in OD tube, rated 689 bar and 454 °C (849 °F). It is a compression type fitting with sleeve installation and a UNF nut thread. ISO 9001 and CE certification are stated for the item.

How it works

The tube end is pushed into the fitting body and the nut is tightened. The back ferrule drives the front ferrule against the body cone, where it seals, and the front ferrule swages onto the tube for grip. Two tubes meet at the elbow body without an added joint, which is how the elbow routes lines around obstacles in instrument and process assemblies.

What is included

• Elbow body with two nuts and two ferrule sets; minimum order 20 pieces

Specify for your project

• Tube outside diameter, if other than 1/2 in
• Tube wall thickness and material
• Working pressure and temperature
• Quantity

This description defines the product family. Guaranteed performance, included hardware, exclusions, interfaces and acceptance criteria are stated only in the project-specific technical proposal and approved datasheet.

Product Details

• Model Number: SS-UE-FT8
• Material: Stainless Steel
• Product name: Tube Union Elbows
• Temperature: (849.2F) 454℃
• Pressure: 689 Bar
• Specification: OD 1/2"
• Thread: UNF
• MOQ: 20pcs
• Installation: Sleeve Type
• Type: Compression
• Certificate: ISO9001and CE
