Single Ferrule Male Elbows

  • The Single Ferrule Male Elbow, model le113584018, connects an inch tube to a female threaded port and turns the line through 90° in one forged part. One end is a single ferrule compression connection for the tube, the other end is a male thread. Users fit it in petroleum, chemical, power, machinery, shipbuilding and water treatment lines.

    How it works

    The tube is pushed through the nut and ferrule into the elbow body. Tightening the nut presses the single ferrule onto the tube to seal and hold it, so no welding or flaring is needed. The male thread end screws into a valve, pump, vessel or manifold port. Thread forms are NPT, BSPT, BSPP, RP, SAE, UNF and UNC, which lets the same elbow body match the port standard of the equipment it mounts on. The forged body has a hexagon for the spanner.

    • Connection: compression and male thread, 90° elbow
    • Size: 1/8 in to 1 1/2 in
    • Threads: NPT, BSPT, BSPP, RP, SAE, UNF, UNC
    • Material: forged stainless steel or carbon steel
    • Media: water, oil, gas, alkaline or acidic liquid
    • OEM marking: accepted

    Specify for your project

    • Tube size within 1/8 in to 1 1/2 in
    • Male thread form and size
    • Working pressure and temperature of the line
    • Material, stainless steel grade or carbon steel
    • Quantity, minimum order 30 pieces

    This description defines the product family. Guaranteed performance, included hardware, exclusions, interfaces and acceptance criteria are stated only in the project-specific technical proposal and approved datasheet.

  • ConnectionCompression and Thread
    TechnicsForged
    Size1/8" - 1 1/2"
    • Single Ferrule Male Elbows
  • Product Details

    • Size: 1/8" - 1 1/2"
    • Technics: Forged
    • Connection: Compression and Thread
    • Shape: Elbow
    • Material: Stainless Steel or Carbon Steel
    • Pressure: 69 Bar to 103 Bar
    • Temperature: on request
    • MOQ: 30pcs
    • Certificate: on request
    • OEM Accepted:Yes
    • Standard: ASME
    • Thread: NPT/ BSPT/ BSPP/ RP/ SAE/ UNF/ UNC
    • Head Code: Hexagon
    • Application: Water, Oil, Gas and Alkaline or Acidic Liquid
    • Certification: on request
    • Usage: Petroleum, Chemical, Power, Machinery, Shipbuilding, Water Treatment, etc.
