    • Single Ferrule Union Tee

    • Stainless Steel Single Ferrule Tee Union DIN2353, ISO8434.1.

      Technical Data


    • MaterialSS316 Stainless Steel
      TypeUnion
      TechnicsForged
      • Single Ferrule Union Tee
      • Single Ferrule Union Tee
      • Single Ferrule Union Tee
      • Single Ferrule Union Tee
      • Single Ferrule Union Tee

    • Product Details

      • Material: SS316 Stainless Steel
      • Type: Union
      • Technics: Forged
      • Connection: Compression
      • Head Code: Hexagon
      • Size: 6mm-42mm
      • Working temperature: high temperature
      • Application: Water, Oil, Gas and Alkaline or Acidic Liquid
      • Certificate: ISO9001, CE
      • Working pressure：high pressure
      • Usage: Petroleum, Chemical, Power, Electronics, Metallurgy, Machinery, Shipbuilding, Water Treatment, etc
      • Standard: DIN2353, ISO8434.1
