HPHT Density Cell

  • The LEHPHTDC is a small high-pressure, high-temperature density cell made of titanium. It holds 4 cc of reservoir fluid and measures fluid density at pressures up to 10,000 psi (700 bar) and temperatures up to 175 °C. PVT laboratories fit it into a fluid line to read density without bringing the sample to atmospheric conditions.

    Design

    The cell body is titanium. Titanium is light and resists corrosion in brines, so the complete cell weighs 182.15 grams and adds little mass to the measuring line. The 4 cc internal volume keeps the sample quantity small, which matters when only a limited volume of live fluid is available. Cell pressure and temperature are the controlled variables; fluid density is the measured one.

    Key data

    ParameterValue
    Volume4 cc
    Max pressure10,000 psi (700 bar)
    Max temperature175 °C
    MaterialTitanium
    Weight182.15 grams

    Typical applications

    • Live oil and condensate density at reservoir pressure and temperature
    • Brine density at pressure
    • Density checks in a PVT or flow line with small sample volume

    Specify for your project

    • Maximum pressure and temperature, within 10,000 psi and 175 °C
    • Fluids to be measured, to confirm titanium compatibility
    • Line connections and how the cell is mounted and heated
    • Readout or density meter the cell works with
    • Number of cells and spares

    This description defines the product family. Guaranteed performance, included hardware, exclusions, interfaces and acceptance criteria are stated only in the project-specific technical proposal and approved datasheet.

    • HPHT Density Cell
  • Features

    • Volume: 4 cc
    • Weight: 182.15 grams
    • Max pressure: 10,000 psi (700 bar)
    • Max temperature: 175°C
    • Material: Titanium

    Benefits

    • Easy to use
    • Cost effective
