NMR Coreflood System

  • Function. Runs NMR (nuclear magnetic resonance) experiments on core samples under reservoir-like conditions. The sample sits in a pressurized core holder made of non-magnetic material.

    Controlled. Confining pressure and pore pressure (reference value 5,000 psi), and temperature (reference value 150 degC).

    Measured. NMR response, saturation and pore-size distribution.

    Each project sets the number of samples, the pressure and temperature ratings, the wetted materials, the seals and the instrumentation.

    Model: LENMRFLD

    This description defines the product family. Guaranteed performance, included hardware, exclusions, interfaces and acceptance criteria are stated only in the project-specific technical proposal and approved datasheet.

    • NMR Coreflood System
  • Key data

    • Confining pressure and pore pressure are both 5,000 psi.
    • The working temperature reaches 150°C at most.
    • Cores of 1” or 1.5” diameter and 1” to 4” length fit.
    • Stainless steel makes up the wetted parts.
    • Services: 220 VAC at 50/60 Hz, and compressed air at 7 bar.

    Advantages

    • The operator can run NMR measurements on core samples at reservoir-like conditions.
