Steam Aging Test Chamber LEST

Steam aging test chamber can simulate the environment of high temperature high humidity, which is used to detect the resistance ability of various products such as metal plating, plastic plating, metal products, electronic appliances, electronic hardware, chemical coating, painting, auto parts, bicycle, sanitary ware, plumbing equipment, screw, fasteners, magnetic materials, locks, metal furniture, sports equipment and other industries under the extremely high temperature high moisture climate, so as to judge the reliability and stability for the products, improve the products quality and provide the basis for the reliability.

Stainless steel SUS#304 made, easy setting operation.
Microcomputer digital LED. Control with time function.
Max. Setting time is 9990 Hrs.
Safety device: including multi over-temperature protection and power off when out of water.
Test the temperature of spare parts, connector passive component and Semiconductor.
Temperature controller: Digital electronic indicators + S. S. R. With P. I. D & timer(Max. 9990 Hrs).

Model No		LEST-3	LEST-4
Test basket.W×H×D(mm)		100540260,3 sets	100540260,4 sets
External Dim.W×H×D(mm)		610540340	760540340
Power supply (AC 1Ψ 220V 60/50Hz)		1.1	1.2
Performance	Temperature range	RT ～ 100℃
	Temp. fluctuation	±0.3℃
	Temp.Uniformity	±0.1℃
	Heating up time	45Min
Material	Exterior chamber materia	SUS#304 stainless steel plate
	Inner chamber materia	SUS#304 stainless steel plate
	Insulation Material	PU Fiberglass wool
System	Heating System	Chrome Steel Strip Wire Heater
	Controlling system	Digital electronic indicators controller+S.S.R.With P.I.D & timer max 9,999mins
Safety protection device		Overheating prevention pretector,Water shortage protector, steam outlet hole, no fuse breaker
Customized service		Welcome to Non-standard,Specail requirements,OEM/ODM orders.
The technical information will be subjected to change without notice

Model	LEST
Brand	LabEquipx
