SS-AFS
CS Socket Weld Flange
Carbon Steel SAE J518, ISO 6162.2 Heavy 6000psi SAE Socket Weld Flange.
Technical Data:
Product Details
- Product name: SAE Socket Weld Flange
- Model Number: SS-AFS
- Media Temperature: -65 to 450 F (-54 to 230 C)
- Standard: ANSI, DIN, ISO
- Type: Welding Flange
- Specification: 1/2-3"
- Material: Stainless Steel or Carbon Steel
- Structure: Flanges
- Connection: Welding
- Sealing Surface: O-Ring
- Manufacturing Way: Forging
- Media: Water, Oil, Gas and Alkaline or Acidic Liquid
| Model | SS-AFS |
| Brand | LabEquipx |
| Standard | ANSI, DIN, ISO |
| Media Temperature | -65 to 450 F (-54 to 230 C) |
