Magnetic Couplings Drive for Industrial High Pressure Reaction LEMCDIHPR

Several important chemical reactions are carried out in somewhat hazardous conditions. Examples of such reactions are as follows:
- Pressure Reactions, such as Hydrogenation, Amination, etc.
- Reactions with noxious gases, easy explosion.
- Manufacture of potent pharmaceuticals, such as hormones, oncology products, etc.
Company can supply Reactors with Top Entry Magnetic Seals. This sealing system comprehensively eliminates all possible leakage risks, by incorporating non-contact magnetic seals. This series magnetic couplings drive is suitable for the industrial production reactor.

100% Sealing. Zero leakage. Low energy cost.
Suitable for industrial reactor with volume 1000 L~50 m3
Full vaccum to 200 bar available；Cooling jacket design for high temperature application.
Materials of SS304, SS316, Hastelloy C, inconel, monel, titanium for resistance to various chemicals.
Low to high torque industrial scale magnetic couplings: static seal with no leakage,which is widely for hydrogenation, amination, noxious gas, easy explosion application.

Type	LEMCDIHPR-MPB type（Belt drive）
For volumes	1000L - 50m³
Motor power	7.5 - 110 kW
Torque range	400 - 7000 N-m
Stirrer speed	0 ~ 500 rpm
Pressure range	Full vacuum / 200 bar
Temperature range	- 40°C to + 350°C
Materials	CS, SS, Hastelloy, Titanium, Nickel, Zirconium, others.
