Cooling Circuit For Autoclave LECCA
The cooling circuit for a chemical reactor allows efficient cooling of the product inside the reactor. The heat carrier is typically a substance based on glycerin or water. The coil can be connected to an additional cooler (chiller) or to a liquid nitrogen circulation line.
The cooling circuit is made of corrosion-resistant material. Usually, the circuit is made of the same material as the autoclave body and cover. The circuit can be equipped with additional radiators to improve cooling efficiency. In case of equipping the installation with an additional chiller, the temperature control of the circuit is carried out by the central control unit.
The cooling circuit for a chemical reactor can be equipped with a precision temperature control system. In this case, the temperature of the environment can be set with an accuracy of 0.1 °C. The accuracy of temperature maintenance allows maintaining stable thermobaric conditions throughout the experiment.
Specifications:
- External working pressure (bar): 1000
- Maximum pressure (bar): 1050
- Working temperature (°C): -200/900
- Coil material: SS 316/Has C276/Titan
- Connection: 1/8'' NPT
Options:
- Precision temperature control
- Chiller
- Internal radiators
- Liquid nitrogen recirculation system
Features:
- The shape of the coil can be customized according to customer requirements. The coil can be equipped with internal radiators, significantly increasing the cooling speed of the internal medium.
- Connection can be made exclusively to the required thread.
- In the case of a circuit execution in conjunction with a stirrer, the circuit shape can be adapted to the type of impeller, reducing the formation of eddy currents during mixing.
| Model | LECCA |
| Brand | LabEquipx |
